Description
For 1″ to 1-3/8″ Overlays.
COMPACT BLUMOTION Hinges are a one-piece hinge, specifically designed for face frame cabinets and interchangeable with current COMPACT Hinges. The soft-close feature is built right into the hinge cup, which means doors close silently each and every time. The BLUMOTION feature is adaptable, so even if you slam the door, you won’t damage it. The door will still close softly for the life of the hinge.
Opening angle: 110
Overlay: 1-1/4″
Fixing type: Screw-On
Boring pattern: 45 mm
Cup depth: 12.7 mm
Side adjustment:+/-1.6 mm
Cam depth adjustment:+/- 3/32″, – 1/32″
Closing type: Soft-Closing
Mounting type: Wrap-Around
